Switch Security

Overview

Access-layer switches are the first line of defense against rogue DHCP, ARP spoofing, unauthorized MACs, and STP manipulation. CCNA covers port security, DHCP snooping, DAI, and BPDU Guard.

Layer 2 threat model

1. Port security — limit MAC addresses per access port
2. DHCP snooping — block rogue DHCP servers
3. Dynamic ARP Inspection (DAI) — validate ARP against DHCP bindings
4. BPDU Guard — shut access ports that receive spanning-tree BPDUs

Port security

Port security restricts which source MAC addresses may send traffic into an access port. Two common production goals:

• Limit MAC count — stop users from connecting hubs, rogue APs, or small switches behind their desk
• Sticky learning — dynamically learn authorized MACs and persist them to config

Violation modes

interface GigabitEthernet0/5
switchport mode access
switchport access vlan 20
switchport port-security
switchport port-security maximum 2
switchport port-security mac-address sticky
switchport port-security violation shutdown

Maximum MAC addresses: Default is 1. IP phone + PC behind the phone typically needs maximum 2 (phone MAC + PC MAC on the same access port).

Recovery from err-disable

1. Remove the offending device
2. shutdown then no shutdown the interface

Or enable auto-recovery:

errdisable recovery cause psecure-violation
errdisable recovery interval 600

show port-security
show port-security interface GigabitEthernet0/5
show port-security address
show errdisable recovery

DHCP snooping

A rogue DHCP server on an access VLAN can hand out attacker-controlled gateways and DNS — classic man-in-the-middle. DHCP snooping builds a binding table (MAC ↔ IP ↔ VLAN) by inspecting DHCP messages and drops server responses that arrive on untrusted ports.

Trusted vs untrusted

• Trusted ports: Uplinks to legitimate DHCP servers or other switches (where valid server replies enter)
• Untrusted ports: End-user access ports — DHCP server messages are dropped

ip dhcp snooping
ip dhcp snooping vlan 10,20
!
interface GigabitEthernet0/1
description Uplink to core / DHCP server path
ip dhcp snooping trust

Exam scenario

PC receives IP 10.10.10.50 from rogue server with gateway 10.10.10.99 (attacker). With snooping enabled, the rogue DHCPOFFER/ACK on an untrusted access port is dropped. Only the trusted server path succeeds.

show ip dhcp snooping
show ip dhcp snooping binding

Dynamic ARP Inspection (DAI)

ARP poisoning maps a victim's IP to the attacker's MAC — intercepting traffic at Layer 2. DAI compares ARP packets against the DHCP snooping binding table. If sender IP/MAC/VLAN don't match a valid binding, the ARP packet is dropped.

DAI is not performed on trusted ports — configure trust on uplinks where ARP from legitimate routers is expected.

ip arp inspection vlan 10,20
!
interface GigabitEthernet0/1
ip arp inspection trust
ip dhcp snooping trust

Non-DHCP clients

Hosts with static IP need manual ARP ACLs or static DHCP snooping bindings — otherwise DAI drops their ARP. CCNA labs usually assume DHCP clients.

show ip arp inspection
show ip arp inspection statistics
show ip dhcp snooping binding

BPDU Guard

BPDU Guard protects access ports configured with Portfast. If a user connects an unmanaged switch (or attacker) that sends BPDUs, the port err-disables instead of participating in STP and potentially becoming a loop entry point.

interface GigabitEthernet0/10
spanning-tree portfast
spanning-tree bpduguard enable
!
spanning-tree portfast bpduguard default

Defense-in-depth workflow

Deploy controls in this order on a typical access switch:

1. Port security on all user access ports (maximum 1 or 2 for phone+PC)
2. Portfast + BPDU Guard on those same access ports
3. DHCP snooping for user VLANs — trust only uplinks
4. DAI on the same VLANs — trust uplinks toward routers
5. Verify bindings before enabling DAI in production

Traffic flow on an untrusted access port: frames hit port security first (MAC limit), DHCP server replies are filtered by snooping, then ARP is validated by DAI against the binding table. A BPDU on a Portfast port triggers BPDU Guard err-disable.

Exam checklist

Troubleshooting commands

show port-security interface GigabitEthernet0/5
show ip dhcp snooping binding
show ip arp inspection statistics
show spanning-tree interface GigabitEthernet0/10 detail
show errdisable recovery

Quick lab checklist

1. Configure port security sticky + violation shutdown on Fa0/5
2. Enable DHCP snooping VLAN 10; trust Gi0/1 uplink only
3. Confirm binding with show ip dhcp snooping binding after PC gets DHCP
4. Enable ip arp inspection vlan 10
5. Enable Portfast + BPDU Guard on access range
6. Test: plug cheap switch into access port → expect err-disable
